E-BIKE CHARGER
MPC-BMZ-4202-RS4
Input: 100-240V ~ 50-60Hz (Global Voltage)
Output Voltage: 42V (For 36V Nominal Batteries)
Output Current: 2.0A
Key Features
- Rosenberger Connector: Features the specialized magnetic plug used by BMZ and Brose systems.
- Battery Friendly: 2A charge current is gentle on battery chemistry.
- Lightweight: At only 0.52 kg, it is easy to transport.
Technical Specifications
| Input | 100-240V ~ 50-60Hz (Global Voltage) |
| Output Voltage | 42V (For 36V Nominal Batteries) |
| Output Current | 2.0A |
| Connector Type | Rosenberger (Magnetic) |
| Color | Black |
Compatibility
- Brand Compatibility Guide Suitable for 36V Li-Ion batteries from the following brands/systems using the Rosenberger plug:
- BMZ
- Rotwild
- ZEG
- Derby Cycle (Impulse 2.0 / 3.0 / Evo)
- Alber Neodrives
- Brose
- Go SwissDrive
- SR Suntour
- Gazelle
- Xion
Part Numbers
- Detailed Battery Part Number List: Verified to work with the following battery part numbers (P/N):
- Alber Xion / Neodrives: 19381 (15.5Ah), 19382 (11Ah), 19383 (15.5Ah), 19384 (11Ah), 22804 (11.25Ah), 22938 (14.5Ah), 24892 (14.25Ah), 25945 (16.75Ah)
- Impulse / Derby Cycle / Kalkhoff: 24558-1GP (16.75Ah), 25628-1GP (14.25Ah), 25629-1GP (16.75Ah) 27371-01 (11.25Ah), 27372-01 (13Ah/17.5Ah) 30880-00 (17.25Ah), 31120-00 (13Ah), 31648-01 (16.75Ah), 31649-01 (16.75Ah), 36170-01 (17.25Ah)
- Shimano Eco (BMZ Compatible): 30860-00 (17Ah/17.25Ah), 31121-00 (13Ah), 36171-01 (17Ah/17.25Ah)
- Integrale: 24558-1GP, 31649-01, 36173-01
